Xiaomi Mi TV Master 77 OLED - 76.7" TV Specifications
A brief overview of Xiaomi Mi TV Master 77 OLED - 76.7" TV specifications and features.
This Xiaomi tv comes with an OLED V21 panel and it has a size of 77" (inches) and a refresh rate of 120 Hz. with a 1 ms response time. In addition to that, the screens resolution is 3840 x 2160 with an aspect ratio of 16:9 which is quite ideal.
The overall weight is 37 kg81 lbs and it has a Black color case. For the power consumption it's using 100 V - 120 V and 220 V - 240 V with a safe operating temperature level of 0 °C - 40 °C 32 °F - 104 °F color case.
Brief Specifications
- Brand
- Xiaomi
- Type
- TV
- Size
- 77" (inches)
- Panel
- OLED V21
- Refresh Rate
- 120 Hz
- Min Response Time
- 1 ms
- Screen Aspect Ratio
- 16:9
- Screen Resolution
- 3840 x 2160
General Info
- Type
- TV
- Year
- 2021
- Brand
- Xiaomi
- Model Number
- Mi TV Master 77 OLED
- Size
- 77" (inches)
- Panel
- OLED V21
- Operating System
- MIUI TV 3.0 (Android)
Display
- Screen Size Class
- 77" (inches)
- Diagonal Size
- 76.77 in195 cm1950 mm6.4 ft
- Screen Width
- 66.91 in170 cm1699.57 mm5.58 ft
- Screen Height
- 37.64 in95.6 cm956.009 mm3.14 ft
- Display Type
- OLED V21
- Display Bit Depth
- 10 bits
- Frame Rate Control
- No
- Max Number of Colors
- 1073741824
- Bits
- 30
- Screen Aspect Ratio
- 16:9
- Screen Resolution
- 3840 x 2160
- Screen Pixel Pitch
- 0.443 mm
- Screen Pixel Density
- 57 ppi
- Screen-to-Body Ratio
- 96.52 %
- DCI P3
- 98.5%
- Rec.2020
- 75
- sRGB
- 100 %
- Adobe RGB 1998
- 95.5 %
- Max Screen Brightness
- 1000 cd/m²
- Static Screen Contrast
- 1500000 : 1
- Screen Horizontal Viewing Angle
- 178 °
- Screen Vertical Viewing Angle
- 178 °
- Display Minimum Response Time
- 1 ms
- HDR
- HLG (Hybrid Log Gamma)Dolby VisionDolby Vision IQHDR10HDR10+
- 3D
- No
Size, weight, color
- Case Depth
- 0.32 in0.8 cm8.2 mm0.03 ft
- Case Width with Stand
- 67.83 in172.3 cm1723 mm5.65 ft
- Case Height with Stand
- 40.24 in102.2 cm1022 mm3.35 ft
- Case Depth with Stand
- 11.38 in28.9 cm289 mm0.95 ft
- Case Weight with Stand
- 37 kg81 lbs
- Case Color
- Black
Hardware
- System on Chip or SoC
- MediaTek S900 (MT9950)
- CPU
- ARM Cortex-A73
- CPU Cores
- 4
- CPU Frequency
- 1800
- GPU
- ARM Mali-G52 MC2
- GPU Cores
- 2
- GPU Frequency
- 800
- RAM Memory Size
- 8.5
- Internal Storage
- 64
- TV Tuner
- Analog (NTSC/PAL/SECAM)DTMB
- Built-in Camera
- No
- Network
- LANWi-Fi802.11a (IEEE 802.11a-1999)802.11b (IEEE 802.11b-1999)802.11g (IEEE 802.11g-2003)802.11n (IEEE 802.11n-2009)802.11n 5GHz802.11ac (IEEE 802.11ac)802.11ax (IEEE 802.11ax, Wi-Fi 6)Wi-Fi DirectDLNABluetooth 5.0UWBNFC
- Connectivity
- 1 x Ethernet RJ451 x HDMI 2.01 x Cable/Antenna In (F-type female)1 x S/PDIF1 x AV Composite In 3.5 mm jack2 x HDMI 2.11 x USB 2.01 x USB 3.0
Audio
- Audio Speakers
- 2 x 15W
- Built-in Subwoofer
- 1 x 20
Features
- OS
- MIUI TV 3.0 (Android)
- Cool Features
- IMAX EnhancedMEMC (Motion Estimation Motion Compensation)Primary Color Screen Pro CalibrationXbox endorsedNVIDIA G-Sync CompatibleAI Picture QualityAI Super Resolution (hardware-level)
Ergonomics
- Case Width
- 67.83 in172.3 cm1723 mm5.65 ft
- Case Height
- 38.46 in97.7 cm977 mm3.21 ft
- Vesa Mount Support
- Yes
- VESA Interface Standard Size
- 400 x 400
- Removable VESA Stand
- Yes
- Height Adjustment
- No
- Landscape or Portrait Pivot Support
- No
- Left or Right Swivel Support
- No
- Forward and Backward Tilt Support
- No
Frequency and Interpolation
- Vertical Digital Frequency
- 40 Hz - 120 Hz
- Screen Interpolation Measurement Unit
- NULL
Power
- 110V
- 100 V - 120 V
- 220V
- 220 V - 240 V
- AC Frequency
- 50 Hz - 60 Hz
- Power Consumption in Sleep Mode
- 0.5 W
- Average Power Consumption
- 160 W
Accessories
- Extras
- Metal remote control with Bluetooth and NFC
Certificates and Standards
- Licenses
- TUV Rheinland Low Blue Light Certified (Hardware Solution)
Usage and Storage Requirements
- Safe Operating Temperature Level
- 0 °C - 40 °C 32 °F - 104 °F
- Safe Operating Humidity Level
- 20 % - 80 %
- Internal Storage Temperature
- -15 °C - 45 °C 5 °F - 113 °F
